SICK GTB10-P7211 1068091 G10 Photoelectric Proximity Sensor PNP 950mm

Machine Description

SICK GTB10-P7211, Part No. 1068091, photoelectric proximity sensor from the G10 series. The GTB10-P7211 uses background suppression for reliable object detection and features a maximum sensing range of 20–950 mm. A visible red PinPoint LED provides a precise light spot, while the sensing distance can be adjusted using a 5-turn potentiometer. The sensor operates from 10–30 V DC and provides a PNP switching output with selectable light/dark switching. Maximum output current is 100 mA, with a response time of up to 500 µs and switching frequency of 1,000 Hz. Electrical connection is via a 300 mm cable with 4-pin M12 male connector. The compact rectangular ABS/PMMA housing is rated IP67. Technical Specifications Specification Value Manufacturer SICK Part Number 1068091 Model GTB10-P7211 Series G10 Sensor Type Photoelectric proximity sensor Detection Principle Background suppression Sensing Range Max. 20–950 mm Light Source PinPoint LED Light Type Visible red Wavelength 625 nm Light Spot Ø 8 mm at 700 mm Adjustment 5-turn potentiometer Output PNP Switching Mode Light / dark selectable Supply Voltage 10–30 V DC Current Consumption 20 mA Max. Output Current ≤100 mA Response Time ≤500 µs Switching Frequency 1,000 Hz Connection 300 mm cable + M12 male, 4-pin Protection Rating IP67 Protection Class III Housing Material ABS / PMMA Dimensions 20 × 50 × 39 mm Weight 70 g Operating Temperature -30°C to +60°C Storage Temperature -40°C to +70°C Package Contents 1× SICK GTB10-P7211 sensor, as shown in the photos. Shopify Tags SICK, GTB10-P7211, 1068091, G10, photoelectric sensor, proximity sensor, background suppression, PNP sensor, PinPoint LED, M12, 950mm, 10-30VDC, IP67, industrial automation SEO Keywords SICK GTB10-P7211, SICK 1068091, G10 photoelectric sensor, background suppression sensor, PNP proximity sensor, 950mm sensor, SICK G10 Meta Title SICK GTB10-P7211 1068091 Photoelectric PNP Sensor 950mm Meta Description SICK GTB10-P7211 1068091 G10 photoelectric proximity sensor with background suppression, PNP output, 20–950 mm range, 10–30 V DC and M12 connector.
