Allen-Bradley 1734-IB8 Series D POINT I/O 8-Point 24V DC Sink Digital Input Module

Machine Description

Allen-Bradley 1734-IB8 Series D POINT I/O digital input module for industrial automation and distributed I/O applications. The 1734-IB8 provides 8 digital sinking input channels for 24V DC signals and is part of the Allen-Bradley / Rockwell Automation Bulletin 1734 POINT I/O family. The module has a nominal 24V DC input rating with an operating input range of 10–28.8V DC. It draws up to 75 mA at 5V DC from the POINTBus and supports configurable input filtering. This specific unit is Series D, firmware 3.022, manufactured in Singapore. Condition: Used, fully functional. Suitable as a replacement or spare module in compatible Allen-Bradley POINT I/O systems. Verify system configuration, terminal base and firmware requirements before installation. Technical Specifications Specification Value Manufacturer Allen-Bradley / Rockwell Automation Product Family POINT I/O Catalog Number / MPN 1734-IB8 Module Type Digital DC Input Module Number of Inputs 8 Input Type Sinking Nominal Input Voltage 24V DC On-State Input Voltage Range 10–28.8V DC On-State Input Current 2–5 mA Maximum Off-State Input Current 1.5 mA Input Filter 0.5 ms hardware + 0–65 ms selectable POINTBus Current 75 mA max. @ 5V DC Maximum Power Dissipation 1.6 W @ 28.8V DC Operating Temperature -20°C to +55°C Series D Firmware 3.022 Material No. PN-130651 Serial Number 59333735 Country of Manufacture Singapore Manufacturing Date 2017/12/21 Compatibility / Application For Allen-Bradley Bulletin 1734 POINT I/O distributed I/O systems. Designed for 24V DC digital field signals requiring an 8-channel sinking input module. Package Contents 1× Allen-Bradley 1734-IB8 Series D Digital Input Module, exactly as pictured. Shopify Tags Allen-Bradley, Rockwell Automation, 1734-IB8, 1734IB8, Series D, POINT I/O, PointIO, Digital Input, PLC Input Module, 24VDC, 8 Channel, Sink Input, Industrial Automation, PLC, Distributed I/O SEO Keywords Allen Bradley 1734-IB8, 1734 IB8 Series D, POINT I/O input module, 24V DC sink input, 8 point digital input module, Rockwell 1734-IB8, PLC input module Meta Title Allen-Bradley 1734-IB8 Series D 8-Point Digital Input Module Meta Description Used Allen-Bradley 1734-IB8 Series D POINT I/O 8-channel 24V DC sinking digital input module, firmware 3.022, for industrial automation systems.
